PRODUCT DESCRIPTION
Output
Output power capacity 6.0kWatts / 6.0kVA
Max Configurable Power (Watts) 6.0kWatts / 6.0kVA
Nominal Output Voltage 230V
Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load 94.0 %
Output Frequency (sync to mains) 50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages 220, 240
Load Crest Factor 3 : 1
Topology Double conversion online
Waveform type Sine wave
Output Connections 4) IEC 60320 C13 (4) IEC 320 C13
Bypass Internal bypass (automatic and manual)
Input
Nominal Input Voltage 230V
Input frequency 40 - 70 Hz/
Input Connections Hard wire 3-wire (1P + N + E)
Cord Length 1.5meters
Input voltage range for main operations 110 - 300 Adjustable (half load), 176 - 300V
Number of Power Cords 1
Efficiency at Full Load 94.0 %
Batteries & Runtime
Battery type Lead-acid battery
Included Battery Modules 1
Typical recharge time 3hour(s)
Battery Charge Power (Watts) 373 Watts
Runtime View Runtime Graph (Available in Technical Tab on site)
View Runtime Chart (Available in Technical Tab on site)
Communications & Management
Interface Port(s) DB-9 RS-232, Intelligent Smart Slot, USB
Control panel Multifunction LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO) Yes
Available SmartSlot™ Interface Quantity 1
Surge Protection and Filtering
Surge energy rating 600Joules
Physical
Maximum Height 685MM, 68.5CM
Maximum Width 190MM, 19.0CM
Maximum Depth 374MM, 37.4CM
Net Weight 54.0KG
Shipping weight 66.0KG
Shipping Height 910MM, 91.0CM
Shipping Width 290MM, 29.0CM
Shipping Depth 495MM, 495CM
Color Black
Standard warranty 2 years repair or replace
